Casting Defects

Sep. 14, 2017

Casting Defects

A casting defect is an undesired irregularity in a metal casting process. Some defects can be tolerated while others can be repaired, otherwise they must be eliminated. They are broken down into five main categories: gas porosity, shrinkage defects, mold material defects, pouring metal defects, and metallurgical defects.

The terms "defect" and "discontinuity" refer to two specific and separate things in castings. Defects are defined as conditions in a casting that must be corrected or removed, or the casting must be rejected. Discontinuities, also known as "imperfections", are defined as "interruptions in the physical continuity of the casting". Therefore, if the casting is less than perfect, but still useful and in tolerance, the imperfections should be deemed "discontinuities".


There are many types of defects which result from many different causes. Some of the solutions to certain defects can be the cause for another type of defect.

The following defects can occur in sand castings. Most of these also occur in other casting processes.

1.Shrinkage defects

Shrinkage defects can occur when standard feed metal is not available to compensate for shrinkage as the thick metal solidifies. Shrinkage defects can be split into two different types: open shrinkage defects and closed shrinkage defects. Open shrinkage defects are open to the atmosphere, therefore as the shrinkage cavity forms air compensates. There are two types of open air defects: pipes and caved surfaces. Pipes form at the surface of the casting and burrow into the casting, while caved surfaces are shallow cavities that form across the surface of the casting.

Closed shrinkage defects, also known as shrinkage porosity, are defects that form within the casting. Isolated pools of liquid form inside solidified metal, which are called hot spots. The shrinkage defect usually forms at the top of the hot spots. They require a nucleation point, so impurities and dissolved gas can induce closed shrinkage defects. The defects are broken up into macroporosity and microporosity (or microshrinkage), where macroporosity can be seen by the naked eye and microporosity cannot.

2.Gas porosity

Gas porosity is the formation of bubbles within the casting after it has cooled. This occurs because most liquid materials can hold a large amount of dissolved gas, but the solid form of the same material cannot, so the gas forms bubbles within the material as it cools.[6] Gas porosity may present itself on the surface of the casting as porosity or the pore may be trapped inside the metal, which reduces strength in that vicinity. Nitrogen, oxygen and hydrogen are the most encountered gases in cases of gas porosity. In aluminum castings, hydrogen is the only gas that dissolves in significant quantity, which can result in hydrogen gas porosity.For casting that are a few kilograms in weight the pores are usually 0.01 to 0.5 mm (0.00039 to 0.01969 in) in size. In larger casting they can be up to a millimeter (0.040 in) in diameter.

To prevent gas porosity the material may be melted in a vacuum, in an environment of low-solubility gases, such as argon or carbon dioxide,[10] or under a flux that prevents contact with the air. To minimize gas solubility the superheat temperatures can be kept low. Turbulence from pouring the liquid metal into the mold can introduce gases, so the molds are often streamlined to minimize such turbulence. Other methods include vacuum degassing, gas flushing, or precipitation. Precipitation involves reacting the gas with another element to form a compound that will form a dross that floats to the top. For instance, oxygen can be removed from copper by adding phosphorus; aluminum or silicon can be added to steel to remove oxygen. A third source consists of reactions of the molten metal with grease or other residues in the mould.

Hydrogen is normally produced by the reaction of the metal with humidity or residual moisture in the mold. Drying the mold can eliminate this source of hydrogen formation.

Gas porosity can sometimes be difficult to distinguish from microshrinkage because microshrinkage cavities can contain gases as well. In general, microporosities will form if the casting is not properly risered or if a material with a wide solidification range is cast. If neither of these are the case then most likely the porosity is due to gas formation.

Blowhole defect in a cast iron part.

Tiny gas bubbles are called porosities, but larger gas bubbles are called a blowholes or blisters. Such defects can be caused by air entrained in the melt, steam or smoke from the casting sand, or other gasses from the melt or mold. (Vacuum holes caused by metal shrinkage (see above) may also be loosely referred to as 'blowholes'). Proper foundry practices, including melt preparation and mold design, can reduce the occurrence of these defects. Because they are often surrounded by a skin of sound metal, blowholes may be difficult to detect, requiring harmonic, ultrasonic, magnetic, or X-ray (i.e., industrial CT scanning) analysis.

3.Pouring metal defects

Pouring metal defects include misruns, cold shuts, and inclusions. A misrun occurs when the liquid metal does not completely fill the mold cavity, leaving an unfilled portion. Cold shuts occur when two fronts of liquid metal do not fuse properly in the mold cavity, leaving a weak spot. Both are caused by either a lack of fluidity in the molten metal or cross-sections that are too narrow. The fluidity can be increased by changing the chemical composition of the metal or by increasing the pouring temperature. Another possible cause is back pressure from improperly vented mold cavities.

Misruns and cold shuts are closely related and both involve the material freezing before it completely fills the mold cavity. These types of defects are serious because the area surrounding the defect is significantly weaker than intended.[15] The castability and viscosity of the material can be important factors with these problems. Fluidity affects the minimum section thickness that can be cast, the maximum length of thin sections, fineness of feasibly cast details, and the accuracy of filling mold extremities. There are various ways of measuring the fluidity of a material, although it usually involves using a standard mould shape and measuring the distance the material flows. Fluidity is affected by the composition of the material, freezing temperature or range, surface tension of oxide films, and, most importantly, the pouring temperature. The higher the pouring temperature, the greater the fluidity; however, excessive temperatures can be detrimental, leading to a reaction between the material and the mold; in casting processes that use a porous mould material the material may even penetrate the mould material.

The point at which the material cannot flow is called the coherency point. The point is difficult to predict in mold design because it is dependent on the solid fraction, the structure of the solidified particles, and the local shear strain rate of the fluid. Usually this value ranges from 0.4 to 0.8.

An inclusion is a metal contamination of dross, if solid, or slag, if liquid. These usually are impurities in the pour metal (generally oxides, less frequently nitrides, carbides, or sulfides), material that is eroded from furnace or ladle linings, or contaminates from the mold. In the specific case of aluminium alloys, it is important to control the concentration of inclusions by measuring them in the liquid aluminium and taking actions to keep them to the required level.

There are a number of ways to reduce the concentration of inclusions. In order to reduce oxide formation the metal can be melted with a flux, in a vacuum, or in an inert atmosphere. Other ingredients can be added to the mixture to cause the dross to float to the top where it can be skimmed off before the metal is poured into the mold. If this is not practical, then a special ladle that pours the metal from the bottom can be used. Another option is to install ceramic filters into the gating system. Otherwise swirl gates can be formed which swirl the liquid metal as it is poured in, forcing the lighter inclusions to the center and keeping them out of the casting.If some of the dross or slag is folded into the molten metal then it becomes an entrainment defect.

4.Metallurgical defects

There are two defects in this category: hot tears and hot spots. Hot tears, also known as hot cracking,are failures in the casting that occur as the casting cools. This happens because the metal is weak when it is hot and the residual stresses in the material can cause the casting to fail as it cools. Proper mold design prevents this type of defect.

Hot spots are areas on the surface of casting that become very hard because they cooled more quickly than the surrounding material. This type of defect can be avoided by proper cooling practices or by changing the chemical composition of the metal.
